YDS-IN1535KY-H-070 Wireless Dual Band Gigabit Ceiling Mount Access Point
|
| Model No. YDS-IN1535KY-H-070 |
| Chipset |
MT7621+MT7613+MT7603 |
| DRAM |
DDR2 128MByte |
| FLASH |
16MByte |
| IC |
2.4G MT7603 / 5.8G SKY85735-11*2 |
| Wired Port |
10/100/1000Mbps WAN*1 LAN（POE 48V）*1 DC Port *1（DC 12V） |
| Speed 2.4G |
300Mbps |
| Speed 5.8G |
867Mbps |
| Modulation |
OFDM/BPSK/QPSK/CCK/DQPSK/DBPSK |
| Standard |
IEEE802.11a,IEEE802.11n,IEEE802.11g,IEEE802.11b,IEEE802.3u,IEEE802.3af,
IEEE802.11ac |
| Channel |
2.4G 2412Mhz~2472Mhz / 5.8G 5180Mhz~5825Mhz |
Power
Dissipation |
≤10W |
| Power |
DC 12V 1A / POE 48V |
|
