YDS-INAX35Y-M-H-071 Wireless Wi-Fi6 Dual Band 1800Mbps Ceiling Mount Access Point
|
| Model No. YDS-INAX35Y-M-H-071 |
| Chipset |
MT7621AN+MT7905DN+MT7975DN |
| DRAM |
DDR2 128MByte |
| FLASH |
16MByte |
| IC |
2.4G / 5.8G MT7905DN |
| Wired Port |
10/100/1000Mbps WAN*1 LAN（POE 48V）*1 DC Interface *1（DC 12V） |
| Speed 2.4G |
580Mbps |
| Speed 5.8G |
1201Mbps |
| Modulation |
OFDM/BPSK/QPSK/CCK/DQPSK/DBPSK |
| Standard |
IEEE802.11a,IEEE802.11n,IEEE802.11g,IEEE802.11b,
IEEE802.3u,IEEE802.3af,I EEE802.11ac,IEEE 802.1111ax |
| Channel |
2.4G 2412Mhz~2472Mhz / 5.8G 5180Mhz~5825Mhz |
Power
Dissipation |
≤15W |
| Power |
DC 12V 1.5A / POE 48V |
|
