| Chipset |
QCA8337+RTL8234 |
| Port |
4*10/100/1000Mbps POE Port(Standard 48V Power Supply), 1*10/100/1000
Mbit/s Uplink network port, 1 1*10/100/1000Mbps SFP Uplink Optical Port |
| Support 4 Ports IEEE802.3af/at Standard PoE Power Supply |
| Power |
Power Input Voltage：AC 100-220V 50-60Hz |
| Single Port Maximum Power：30W |
| Power Consumption：4W |
| Maximum Power Consumption：60W |
| Performance |
Backplane Bandwidth：12Gbps |
| Packet Forwarding Speed : 11.9Mpps |
| All Ports Line Speed Forwarding |
| The Size of the MAC Address Table：4K |
| Auto MDI/MDI-X: Yes |
| Standard |
IEEE802.3、IEEE802.3u、IEEE802.3ab、IEEE802.3x、IEEE802.3af、 IEEE802.3at |
| Operating Condition |
Operating Temperature：-20-60℃ |
| Storage Temperature：-50～80℃ |
| Operating Humidity：≤10～90%(non-condensed) |
| Storage Humidity: ≤5～90%(non-condensed) |
| Product Size |
Size: 300*220*30mm |
| Weight: 1.2kg |
| Packing List |
2 Stainless Steel Fixed Rings |
| 1 Specification |
