| Model |
YDS-SW6G V2.2-094 |
| Interface |
4*10/100/1000Mbps RJ45 Ports(PoE Power Supply) |
| 2*10/100/1000Mbps RJ45 Port |
| Standard |
IEEE 802.3、IEEE 802.3u、IEEE 802.3ab、IEEE 802.3z、IEEE 802.3x、IEEE802.1x、
IEEE 802.1q、IEEE 802.1p、IEEE 802.1d、IEEE 802.1w、
IEEE802.3ad、IEEE802.3af、IEEE802.3at |
| PoE Standard |
IEEE802.3af/at |
| PoE Port |
Port 1~4 |
| PoE Single Port Output |
Max.30W |
| Input Voltage |
AC: 100-240V 50/60Hz |
| PoE Total Power |
60W |
| Total Power Supply |
65W |
| RJ45 PoE Power Supply |
Mode A 1/2（+） 3/6（-） |
| MAC Address Table |
8K, Auto-learning, Auto-aging |
| Transfer Mode |
Store-and-forward |
| Switching Capacity |
12Gbps |
| Jumbo Frame |
9216Bytes |
| Packet Buffer |
4.1Mbit |
| Packet Forward Speed |
8.93Mpps |
| Operating Temperature |
0℃~40℃ |
| Storage Temperature |
-40℃~70℃ |
| Operating Humidity |
10%~90% RH (Non-condensed) |
| Storage Humidity |
5%~90% RH (Non-condensed) |
Dimensions
(L*W*H) |
220*150*44mm |
| Fan Quantity |
Fanless |
| Overall Weight |
<1.2Kg |
| Network Media(Cable) |
10BASE-T: UTP category 3、4、5 cable (≤100m) |
| 100BASE-TX: UTP category 5, 5e cable (≤100m) |
| 1000BASE-T: UTP category 5e, 6 cable (≤100m) |
| Surge Protection |
Differential mode ±2KV ，Common mode ±4KV |
| MTBF |
>50000 Hours |
| Electrostatic Standard |
Contact ±6KV , Air ±8KV |
