YDS-954G2 V3.2-074 SD-WAN Outdoor 4G Router 300M
|
| Model No. YDS-954G2 V3.2-074 |
| Chipset |
QCA9531 |
| DRAM |
DDR2 128MByte |
| FLASH |
16MByte |
| Port |
1*10/100M（WAN）port , support Auto MDI/MDIX |
| 1*10/100M（LAN）port， support Auto MDI/MDIX |
| Speed |
11b: 11M，5.5M，2M，1Mbps |
| 11g: 54M，48M，36M，24M，18M，12M，9M，6Mbps |
11N:6.5M，13M，13.5M，19.5M，26M，27M，39M，40.5M，52M，54M，58.5M，
65M, 81M, 108M，121.5M，135M，150M，270M，300Mbps |
| Transmission |
DSSS |
| Modulation |
OFDM/BPSK/QPSK/CCK/DQPSK/DBPSK |
| Standard |
IEEE802.11n,IEEE802.11g,IEEE802.11b,IEEE802.3u |
| Protocol |
CSMA/CA,TCP/IP,IPX/SPX,NetBEUI,DHCP,NDIS3,NDIS4,NDIS5 |
| Channel |
2412～2472MHz |
| Power Dissipation |
≤10W |
| Power |
≤10W |
|
