YDS-TX26-32YW-077 300Mbps Stable Transmission AP High Gain & Wide Coverage for Hotel and Plazas
|
| Model No. YDS-TX26-32YW-077 |
| Chipset |
Atheros QCA9531 QCA9533 600MHz |
| DRAM |
DDR2 128MByte |
| FLASH |
16MByte |
| Wired Port |
10/100Mbps LAN*2 |
| Data Rate |
11b: 11M，5.5M，2M，1Mbps |
| 11g: 54M，48M，36M，24M，18M，12M，9M，6Mbps |
11N:6.5M，13M，13.5M，19.5M，26M，27M，39M，40.5M，52M，54M，58.5M，
65M，81M, 108M，121.5M，135M，150M，270M，300Mbps |
| Transmission |
DSSS |
| Modulation |
OFDM/BPSK/QPSK/CCK/DQPSK/DBPSK |
| Standard |
IEEE802.11n,IEEE802.11g,IEEE802.11b,IEEE802.3u, |
| Protocol |
CSMA/CA,TCP/IP,IPX/SPX,NetBEUI,DHCP,NDIS3,NDIS4,NDIS5 |
| Frequency |
2312～2732MHz |
| Power Dissipation |
≤5W |
| Power |
POE 48V 0.5A |
|
