| Model |
YDS-SW16G-2F V2.2-096 |
| Interface |
16*10/100/1000Mbps RJ45 Ports |
| 2*1000Mbps SFP Slots |
| Standard |
IEEE 802.3、IEEE 802.3u、IEEE 802.3ab、IEEE 802.3z、IEEE 802.3x、
IEEE 802.1x、IEEE 802.1q、IEEE 802.1p、IEEE 802.1d、IEEE 802.1w、
IEEE 802.3ad、IEEE802.3af、IEEE802.3at |
| PoE Standard |
IEEE802.3af/at |
| MAC Address Table |
8K, Auto-learning, Auto-aging |
| Jumbo Frame |
9K Byte |
| Packet Buffer |
4.1M bit |
| Transfer Mode |
Store-and-forward |
| Switching Capacity |
36Gbps |
| Packet Forward Speed |
26.78Mpps |
| PoE Port |
Port 1~16 |
| RJ45 PoE Power Supply |
Mode A 1/2（+）3/6（-） |
| PoE Port Output |
Voltage：55V DC 30W MAX |
| PoE Total Power |
250W |
| Power Total Power |
260W |
| Input Voltage |
AC :100-240V 50/60Hz |
| Operating Temperature |
0℃~40℃ |
| Storage Temperature |
-40℃~70℃ |
| Operating Humidity |
10% ~ 90% RH (non-condensed) |
| Storage Humidity |
5% ~ 90% RH (non-condensed) |
| Dimensions（L*W*H) |
440*207*44mm |
| Fan Quantity |
2 |
| Overall Weight |
<1Kg |
| Network Media(Cable) |
10BASE-T：UTP category 3、4、5 cable（≤100m） |
| 100BASE-TX：UTP category 5,5e cable（≤100m） |
| 1000BASE-T：UTP category 5e, 6 cable（≤100m） |
| Surge Protection |
Differential mode ±2KV , Common mode ±4KV |
| MTBF |
>50000 hour |
| Electrostatic Standard |
Contact ±6KV , Air ±8KV |
